How parametric modelling can help schools cut carbon and improve comfort
Monica Donaldson-Balan Associate building physics engineer, Mott MacDonald
Image: Anakimfor | Dreamstime.com
Mott MacDonald has used parametric modelling to meet Department for Education design requirements on more than 50 school refurbishments. Monica Donaldson-Balan explains.
The start of the new school term puts a focus on academic achievement and, while having a new pencil case is nice, the learning environment also has a role to play. But designing for that, along with making sure school buildings are carbon efficient, as well as meeting all the other requirements, is a complex balancing act.
Delivery of just that was achieved for the Department for Education (DfE) on new-build and refurbishment projects for more than 50 schools across the UK by Mott MacDonald through the use of parametric modelling. The technique was used to quickly review numerous design iterations to develop the optimum solution to maximise student comfort and reduce the carbon footprint of the schools.
